Topology Selection

The 20G series switches support 10G and 1G SFP modules, enabling high-speed connectivity and flexible network configuration. The 2G Series is compatible with 1G SFP modules and select models also support 100M SFP modules. With this variability, the devices can be tailored to specific network requirements, ensuring optimal performance and compatibility with different connection types.


The switches support the LAN-RING protocol, which provides fast network reconfiguration times of up to 30 ms, minimizing downtime and ensuring high availability. They also enable the use of the RSTP protocol, which is suitable for MESH network topologies and ensures efficient redundancy and connection stability. All key network status information is sent in the form of SNMP traps, enabling fast and efficient monitoring and management of network traffic. A new feature will be the support of LACP protocols in G-series switches.




SFP modules in our offer have SC or LC terminations. In addition, the 100-megabit and gigabit models can be used universally on both single-mode and multimode fibers.
