Power Redundancy

All BOX Series switches support two independent power inputs that allow operation in the 10-30 VAC and 10-60 VDC range. This flexibility provides reliable power in a variety of environments and applications. However, if PoE technology is used, a minimum 48 VDC power supply must be provided. With this variability, the switches can be deployed in a wide range of industrial and commercial solutions where power stability and redundancy are important.

20G-2X.8C.F(G)-UNIT/1U

The 20G-2X.8C.F(G)-UNIT/1U features two 230 VAC power inputs, ensuring reliable operation even in the event of a single power supply failure. In addition to this variant, a version with one 230 VAC input and a second input in the 20-60 VDC range is also available. This flexibility allows the device to adapt to different power conditions and increases its versatility for deployment in various types of networks and industrial applications. In addition to a single 230 VAC input, the 20G-2X.1.24(16).F(G)-POE-750-UNIT/1U and 20G-2X.5.1.16.F(G)-POE-750-UNIT/1U switches offer two 10-60 VDC inputs.
